How to Change a Type B Fuse on a Toyota RAV4

To change a Type B fuse on a Toyota RAV4, turn the vehicle off, open the fuse box, find the blown fuse using the diagram in your owner’s manual, pull it out with the fuse puller, and push in a new fuse of the same amp rating. Toyota’s manual lists fuses by name and amp rating, and “Type B” is a nickname that some guides use, so identify the fuse by its position and rating, not the nickname. Related: how to change a fuse in a Toyota RAV4 and how to change the ALT fuse on a Toyota RAV4.

How to Find Your Fuse Box: A Simple Guide

Type B fuse on a Toyota RAV4 fuse box

There are usually two fuse boxes: one in the engine bay and one inside the cabin, often near the driver’s footwell or the glove box. The manual shows both locations and a diagram of what each fuse protects.

Why the Type B Fuse on a Toyota RAV4 Matters

A fuse protects a circuit by burning through when the current is too high. When one blows, the circuit it protects stops working. If the new fuse blows again, there is a fault in the circuit.

How to Safely Remove a Blown Type B Fuse

  1. Turn the vehicle off and take out the key or fob.
  2. Open the fuse box cover and read the diagram on the cover or in the manual.
  3. Pull out the suspected fuse with the fuse puller (often clipped in the fuse box).
  4. Hold it up to the light. A blown fuse has a broken wire inside.

Best Practices for Installing a New Type B Fuse

install type b fuse securely
  • Use a fuse with the same amp rating and the same type.
  • Never fit a higher-rated fuse, since it can cause overheating or a fire.
  • Push the new fuse in firmly and refit the cover.

What to Do If Your Vehicle Still Doesn’t Work After Fuse Replacement?

Check that you replaced the right fuse, and look at the other fuses for that circuit. If the vehicle still does not work, the problem may be a relay, a wiring fault or a failed part.

Troubleshooting Common Problems After Replacing Your Type B Fuse

  • The new fuse blows at once: there is a short circuit. Do not keep replacing fuses.
  • The fuse is hard to fit: check the type and rating.
  • Still no power: check the relay and the connectors.

Tips for Maintaining Your RAV4’s Electrical System and Type B Fuse

rav4 electrical system maintenance
  • Keep spare fuses of the common ratings in the vehicle.
  • Keep the fuse box covers closed and dry.
  • Have any recurring blown fuse diagnosed.

When to Seek Professional Help for Fuse Issues

See a shop if a fuse keeps blowing, you see burn marks or melted plastic, or you are not sure which fuse to replace.

Frequently Asked Questions

What Is the Most Common Problem With a Toyota RAV4?

It depends on the model year. Check the recalls and owner complaints for your year at nhtsa.gov.

Can You Replace Car Fuses Yourself?

Yes, in most cases. It takes a few minutes and only needs a fuse puller and the right replacement fuse.

Which Fuse Is for the Passenger Window?

It depends on the model year. Check the fuse diagram in your manual for the power window fuse.

What Type of Fuses Does the 2019 RAV4 Take?

Most Toyota vehicles use blade fuses of different sizes, plus some larger cartridge-type fuses. The diagram in the manual shows the type and the rating of each one.

Conclusion

To change a Type B fuse on a Toyota RAV4, find the right fuse in the diagram and replace it with the same rating. If it keeps blowing, have it checked.
